Views: 0 Author: Site Editor Publish Time: 2026-06-24 Origin: Site
Regulatory Reference: EMSD Type Approval Technical Appendix
Application Registry: BM00007544
Equipment Profile: Shandong JiuRoad Corp – PCXC Series Mechanized Vehicle Parking System
Shandong JiuRoad Corp has successfully secured the Hong Kong Electrical and Mechanical Services Department (EMSD) Type Approval for its PCXC Series Mechanized Vehicle Parking System (MVPS). Validated through rigorous test reports and an official certificate of conformity, the equipment fully satisfies the strict safety benchmarks of the European standard EN14010.
The following sections detail the officially approved mechanical framework and operational specifications.
Operational Format: An automated Mechanized Vehicle Parking System (MVPS) utilizing a continuous rotary carousel architecture.
Volumetric Capacity: Purpose-built and certified to accommodate configurations of up to $10$ or $20$ individual parking spaces per standalone hardware unit.
Handling Mechanism: Deploys dedicated load carriers engineered to individually support and transport vehicles seamlessly throughout the vertical rotation cycle.
The reliable operation of the PCXC Series is driven by a highly synchronized chain-drive ecosystem:
Primary Propulsion: The entire mechanism is actuated by a vertical lifting motor, which interfaces with the primary drive sprocket via a reinforced duplex roller drive chain.
Dual-Axis Synchronization:
Front: The main drive sprocket connects directly to the front transmission sprocket, powering the front lifting chain.
Rear: A rigid drive axle transfers power to the rear transmission sprocket, ensuring the rear lifting chain operates in perfect operational sequence with the front.
Physical stability during the equipment's cycle rotation is a critical safety factor. The EMSD has validated the following structural motion-restriction designs:
Suspension Dynamics: Triangular plates are anchored to both the front and rear lifting chains. These vital components suspend the individual vehicle carriers and facilitate their continuous rotary movement.
Anti-Swing Guide Rails: The carrier guide rollers are constrained within precision-engineered guide rails. This design organically limits the direction of movement, guaranteeing strict horizontal alignment and completely neutralizing hazardous mechanical sway during vertical transit.
Disclaimer: The operational parameters and specific capabilities governed by the manufacturer's make and the exact certificate of conformity operate strictly within the boundaries of this EMSD-approved technical schedule.
---
The JiuRoad PCXC Series arms developers with a formidable, regulation-ready solution to overcome severe urban space limitations and charging, entirely backed by the rigorous EMSD clearance and EN14010 European standards.
As we scale our international footprint, Shandong JiuRoad Corp is actively seeking exclusive regional distributors and strategic project partners.
Whether you are an EPC contractor, a smart city infrastructure developer, or an established equipment agent, this heavily certified product offers a direct pathway to dominating the high-margin Integrated Charging and Parking Equipment.
Take the lead in your local market. Reach out to our global commercial development team today to discuss exclusive territorial rights, partnership tiers, and detailed project quotation structures.
